Refrigeration Unit for Cold Transportation HT-780
Product Details
| Model: | HT-780 | Temperature Range: | -25°C To +25°C |
|---|---|---|---|
| Cooling Capacity(0℃): | 7300W | Cooling Capacity(-18℃): | 4350W |
| Application Box Volume: | ≤32 M3 | Outside Temperature: | 30°C To 50 °C |
| Compressor Brand: | Guangyu | Compressor Mode: | GY21 |
| Compressor Displacement: | 209 CC | Condenser: | Parallel Flow Condenser |
| Evaporator: | Inner Grooved Copper Tube&aluminum Fin | ||
| Highlight |
HT-780 refrigeration unit for trucks,vehicle refrigeration unit with warranty,cold transport refrigeration system HT-780 |
||
Product Description
- Direct engine drive system for efficient operation
- Specifically designed for 40m³ refrigerated transport vehicles
- Ideal for transporting chilled & frozen foods, medical supplies, fruits, vegetables, ice cubes, and seafood
- OEM customization services available
- Low operational and maintenance costs
- Easy installation process
- Suitable for long-distance transportation requirements
- Eco-friendly refrigerant R404A (R134a system also available)
- Corrosion-resistant, high-strength FRP canning material
- Aluminum fin parallel flow condenser - lightweight, compact design with superior heat exchange
- Inner grooved copper tube evaporator with large airflow and enhanced coil protection
- Robust, reliable compressor specifically engineered for R404a systems
- Digital display control panel for minimal operation complexity
- High and low pressure switch safety protection
- Large cooling capacity with dependable performance
Technical Specifications| Unit Model | HT-780 |
| Applicable Temperature | -25°C To +25°C |
| Box Volume | ≤32m³ |
| Cooling Capacity (0℃/+30℃) | 7300 W |
| Cooling Capacity (-18℃/+30℃) | 4350 W |
| Compressor Model | GY21 |
| Compressor Capacity | 209 CC |
| Lubricating Oil | PAG 68 |
| Evaporator Material | Inner grooved copper tube |
| Evaporator Fans | 3 PCS |
| Condenser Material | Parallel flow condenser |
| Condenser Fans | 2 PCS |
| Refrigerant | R404a |
| Refrigerant Charge | 3.0KG |
| Temperature Control | Electronic digital display |
| Safety Protection | High and low pressure switch |
| Defrosting System | Hot gas defrost automatically |
| Evaporator Weight | 33 KG |
| Condenser Weight | 55 KG |
| Evaporator Dimensions | 1240×600×345 |
| Condenser Dimensions | 1480×500×510 |
| Drive Model | Non-independent engine driven |
Product Highlights
HT-780 Refrigeration Unit for Cold Transportation Trucks & Vans The HT-780 refrigeration unit is engineered for reliable temperature control in refrigerated trucks, vans, and lorries. Designed specifically for volumes up to 32m³, this system ensures optimal preservation of chilled and frozen goods ...
