HT-580 Truck Refrigeration Unit with 22m³ Box Volume GY17 Compressor and R404A Refrigerant for Frozen Van

Name: HT-580 Truck Refrigeration Unit with 22m³ Box Volume GY17 Compressor and R404A Refrigerant for Frozen Van
Brand: Sichuan Yinhuasheng Technology Co., Ltd.
SKU: HT-580
Availability: InStock

Brand Name:	Yinhuasheng/OEM
Model Number:	HT-580
MOQ:	1SET
Price:	Negotiable
Payment Terms:	TT/LC
Supply Ability:	1000 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE/ISO9001

Model:

HT-580

Cooling Capacity(0℃):

5450W

Cooling Capacity(-18℃):

2750W

Application Box Volume:

≤22 M³

Outside Temperature:

30°C To 50 °C

Compressor Brand:

Guangyu

Compressor Mode:

GY17

Compressor Displacement:

177 CC

Evaporator:

Inner Grooved Copper Tube&aluminum Fin

Condenser:

Parallel Flow Condenser

Packaging Details:

Customized packaging

Supply Ability:

1000 sets per month

Highlight:

22m³ Box Volume Truck Refrigeration Unit

GY17 Compressor Refrigerated Truck Unit

R404A Refrigerant Van Chiller Unit

Product Description

HT-580 Frozen Van Truck Refrigeration Units with Compressor Mode GY17

Product Overview

Engine-driven refrigeration unit designed for 22m³ refrigerated trucks, ideal for transporting chilled and frozen foods, medical supplies, fruits, vegetables, ice cubes, and seafood.

Key Features

Direct engine drive system
OEM customization services available
Low operational and service costs
Easy installation process
Suitable for long-distance transportation

Technical Specifications

Eco-friendly refrigerant R404A (R134a system also available)
Corrosion-resistant, high-strength FRP canning material
Aluminum fin parallel flow condenser - lightweight and compact with excellent heat exchange
Inner grooved copper tube evaporator with large airflow and coil protection
Strong, reliable compressor specifically designed for R404a systems
Digital display control panel for minimal operation
HP and LP switch safety protection
Large cooling capacity with reliable performance

Product Images

Technical Parameters

Unit Model	HT-580
Applicable Temperature	-25℃ ~ +25℃
Box Volume	≤22m³
Cooling Capacity (0℃/+30℃)	5450 W
Cooling Capacity (-18℃/+30℃)	2750 W
Compressor Model	GY17
Compressor CC	177 CC
Lubricating Oil	PAG 68
Evaporator Material	Inner grooved copper tube
Evaporator Fans	3 PCS
Condenser Material	Parallel flow condenser
Condenser Fans	2 PCS
Refrigerant	R404a
Refrigerant Charge	2.2KG
Temperature Adjustment	Electronic digital display
Safety Protection	High and low pressure switch
Defrosting	Hot gas defrost automatically
Evaporator Weight	30 KG
Condenser Weight	45 KG
Evaporator Dimensions	1400660250
Condenser Dimensions	1345520430
Drive Model	Non-independent engine driven
