Refrigeration Compressor for Cold Chain | Heavy-Duty AC Compressor for Refrigerated Trucks & Containers
Product Details
| Brand: | OEM / Customizable | Number Of Cylinders: | 5 |
|---|---|---|---|
| Refrigerant Type: | R404a | Lubricant Oil: | POE-68 |
| Theoretical Displacement:: | 104 Ml/r | Application: | Cold Chain, Refrigerated Trucks, Cold Storage, Containers |
| Supply Ability: | In Stock & Bulk Order Available | ||
| Highlight |
heavy-duty refrigeration compressor,cold chain AC compressor,refrigerated truck compressor |
||
Product Description
| Model | 5S11 |
| Number of Cylinders | 5 |
| Refrigerant | R404a |
| Lubricant Oil | POE-68 |
| Theoretical Displacement | 104 ml/r |
| Oil Charge | 140 mL |
| Speed (r/min) | Cooling Capacity (kW) | Input Power (kW) | COP (Energy Efficiency Ratio) | Volumetric Efficiency (%) |
|---|---|---|---|---|
| 1000 | 1.408 | 1.482 | 0.95 | 50.75 |
| 1500 | 2.129 | 2.087 | 1.02 | 51.13 |
| 2000 | 2.851 | 2.768 | 1.03 | 51.96 |
| 2500 | 3.531 | 3.640 | 0.97 | 50.88 |
| 3000 | 3.955 | 4.444 | 0.89 | 47.49 |
- Heavy-Duty 5-Cylinder Construction: The 5-cylinder design and die-cast aluminum housing provide exceptional stability and durability, reducing vibration and extending service life. Anti-corrosion surface treatment ensures resistance to harsh weather and transport conditions.
- High Efficiency & Energy Savings: Optimized piston and valve design maximizes cooling output while minimizing energy consumption. The peak COP of 10,3 at 2000 r/min helps reduce operational costs for fleet owners and cold storage operators.
- Easy Installation & Compatibility: Standardized mounting brackets and interfaces allow for direct replacement of most mainstream cold chain units, eliminating complex modifications. Compatible with R404a refrigerant and POE-68 lubricant, meeting global cold chain equipment standards.
- Reliable 24/7 Performance: Premium bearings and sealing systems minimize wear and leakage, ensuring consistent performance during continuous operation. The 12-month warranty provides additional peace of mind for critical cold chain applications.
Product Highlights
Refrigeration Compressor for Cold Chain | Heavy-Duty AC Compressor for Refrigerated Trucks & Containers Product Overview Our 5S11 R404a refrigeration compressor is a heavy-duty 5-cylinder core component engineered for cold chain logistics, refrigerated trucks, containers, and cold storage equipment. ...
