HT-1280 Transport Refrigeration Unit with 9980W Cooling Capacity for 46~55 m³ Cold Chain Refrigerated Trucks

Name: HT-1280 Transport Refrigeration Unit with 9980W Cooling Capacity for 46~55 m³ Cold Chain Refrigerated Trucks
Brand: Sichuan Yinhuasheng Technology Co., Ltd.
SKU: HT-1280
Availability: InStock

Brand Name:	Yinhuasheng/OEM
Model Number:	HT-1280
MOQ:	1SET
Payment Terms:	TT/LC
Supply Ability:	1000 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Model:

HT-1280

Temperature Range:

-25°C To +25°C

Cooling Capacity(0℃):

9980W

Cooling Capacity(-18℃):

5780W

Application Box Volume:

46~55 M³

Outside Temperature:

30°C To 50 °C

Compressor Brand:

Jianshe

Compressor Mode:

JS38

Compressor Displacement:

313 CC

Condenser:

Parallel Flow Condenser

Evaporator:

Inner Grooved Copper Tube&aluminum Fin

Supply Ability:

1000 sets per month

Highlight:

9980W Cooling Capacity Transport Refrigeration Unit

46~55 m³ Cold Chain Refrigeration Unit

HT-1280 Vehicle Refrigeration Unit

Product Description

Transport Refrigeration Unit for COLD CHAIN refrigerate lorry truck HT-1280

Product Description

This direct engine drive refrigeration unit is designed for 46-55m³ refrigerated trucks, providing reliable temperature control for chilled and frozen goods including foods, medical supplies, produce, ice, and seafood. OEM customization services are available.

Key Advantages

Vehicle engine driven system
Low operational and maintenance costs
Easy installation process
Ideal for long-distance transportation

Technical Features

Eco-friendly R404A refrigerant (R134a system available)
Corrosion-resistant, high-strength FRP canning material
Aluminum fin parallel flow condenser for efficient heat exchange
Inner grooved copper tube evaporator with protective design
Reliable R404a-specific compressor
User-friendly digital display control panel
HP/LP switch safety protection
High cooling capacity with stable performance

Technical Specifications

Unit Model	HT-1280
Temperature Range	-25°C to +25°C
Box Volume	46-55m³
Cooling Capacity	0℃/+30℃: 9980 W -18℃/+30℃: 5780 W
Compressor	Model: JS32 CC: 313 CC Lubricating Oil: PAG 68
Evaporator	Material: Inner grooved copper tube Fans: 3 PCS
Condenser	Material: Parallel flow condenser Fans: 4 PCS
Refrigerant	R404a (Charge: 4.2KG)
Controls	Electronic digital display temperature adjustment
Safety	High and low pressure switch protection
Defrosting	Automatic hot gas defrost
Weight/Dimensions	Evaporator: 41.5 KG (1480×600×350 mm) Condenser: 63 KG (2130×385×360 mm)
Drive Model	Non-independent engine driven
